300m x Medium duty 520 truss by Total Fabrications - Shropshire

Description

520 A Type Truss

The combination of large load capacity and compactness makes the Medium Duty truss ideal for most general applications involving spans of up to 18 metres.

Shape Square
520.7 x 520.7
1872kg UKL @ 9m
M16 x 45mm grade 8.8 HT Nuts & bolts

Straight Truss
13x 6000mm
1x 5000mm
1x 4000mm
33x 3000mm
6x 2000mm
2x 5580mm
2x 5540mm
6x 4200mm
6x 4120mm
4x 3270mm
3x 2440mm
2x 1310mm

Corners
2x 3 way corner
6x 4 way corner

Pivot Sections
4x Truss pivot section book hinge

Material Specifications
Main Chord: 50.8mm x 3.25mm
Braces: 25.44mm x 3.25mm
Material: EN AW-6082 T6

Design Specification
Manufactured in accordance with
BS EN 1090-3:2008 : Technical Requirements for aluminium structures
EN ISO 9001:2008 : Quality management systems
BS EN 1999 Pt 1-1 : Design of Aluminium Structures, General structural rules
BS EN 17115:2018 : Specifications for design and manufacture of aluminium and steel
trusses.

Load Terms
All loads are given in Kilograms
Allowance has been made for self-weight of truss
Allowance has been made for frequent use factor of 85% according to prEN17115
The payload of the truss has been calculated as a permanent action. Should it be necessary to consider the payload as a variable action, the tabulated figures should be reduced to 90% of the given values

Cad
3d Cad blocks available
