Sold 16x Chauvet IP Rated LED Battern - For Sale - Bedfordshire

Description

16 x Chauvet Colorband PIX IP Rated LED Battern

Comes with 13a - IP Power and 3 pin DMX IP Converters

5m IP power and 5m IP Data cable also available.

From the Chauvet web site

COLORband PiX
Great for use as a powerful wash with the additional eye candy of pixel mapping effects, COLORband PiX is a must-have fixture for mobile DJs or club installers looking for high-impact visuals on a budget. Full-size, linear pixel mapping fixture easily generates video effects and animations when multiple units are used together. Individual control over 12 tri-color LEDs allows for custom looks at any event and impressive, pre-built programs are accessible with or without DMX. Multiple DMX personalities and onboard 3- and 5-pin DMX connectors increase control options.

With onboard 3- and 5-pin XLR DMX connectors
Includes multiple DMX personalities for a wide variety of programming styles
Nearly eliminate multicolor shadows with high-power, tri-color LEDs
Achieve flicker-free video operation with high-frequency LED dimming
Save time running cables and power cords by power linking multiple units
Create large, coordinated light shows with COLORband™ PiX IP, COLORband™ PiX Mini, and COLORband™ PiX-M fixtures in Master/Slave mode
Ideal for quiet applications due to silent operation and no moving parts
Sound-activated programs dance to the beat of the music
Easily transports in the optional CHS-60 VIP Gear Bag
Combine multiple units together using the CBB-6 mounting bracket

Specifications
DMX Channels: 3, 4, 6, 7, 9, 12, 18 or 36
DMX Connectors: 3- and 5-pin XLR
Light Source: 12 LEDs (tri-color RGB) 3 W (1,050 mA), 50,000 hours life expectancy
Strobe Rate: 0 to 30 Hz
PWM Frequency: 1,200 Hz
Beam Angle: 20°
Field Angle: 34°
Illuminance: 2,325 lux @ 2 m
Power Linking: 11 units @ 120 V; 20 units @ 230
VInput Voltage: 100 to 240
VAC, 50/60 Hz (auto-ranging)
Power and Current: 82 W, 0.7 A @ 120 V, 60 Hz
86 W, 0.4 A @ 230 V, 50 Hz
Weight: 8.9 lb (4 kg)
Size: 41.6 x 2.5 x 6.1 in (1,057 x 64 x 154 mm)
Approvals: CE, MET

Item code 03020469
Item number ColorbandPix

Click to download the manual

This item is now sold

Price: Sold
